ANSI Aluminum Flange
ANSI Aluminum Flange
Designed to provide a secure, standardized connection point in aluminum industrial piping systems. Ideal for compressed air, vacuum, and inert gas applications, this flange allows contractors to bolt pipe sections or equipment together using ANSI-compliant dimensions. Made from corrosion-resistant aluminum, it features metal clamshell union connectors lug ring design for leak-free connection. Its full-volume flow and rugged construction ensure long-term reliability in demanding environments. Reusable and easy to maintain, the ANSI flange is perfect for permanent installations requiring precision alignment and robust sealing performance.
Key Features
- Durable Construction: Made from Aluminum, offering superior resistance to corrosion, vibration, and thermal variation.
- Weather-Resistant: Performs reliably in outdoor and harsh industrial conditions.
- Metal Clamshell Connectors: Stronger and more durable than polymer alternatives.
- 63โ200mm: Lugged ring for zero risk of disconnection.
- Leak-Free Guarantee: Engineered for superior sealing and longevity compared to traditional pipe systems.
- ย No welding, gluing, brazing, soldering, or thread cutting required.
- Quick Assembly: Supplied with two union connectors for fast, full-volume flow connection.
- Reusable & Easily disassembled and reassembled for maintenance or system upgrades.
- Non-Flammable Materials: Safe for use in high-risk industrial zones.
- ANSI-Compliant Design: Ensures compatibility with standard flanged equipment and piping systems.
Available Sizes
- 2ยฝโ to 10โ
Applications
- Compressed Air (dry, wet, lubricated)
- Vacuum Systems
- Inert Gases (Argon, Helium, Nitrogen, COโ mixes)
Certifications
- ASME B31.1, B31.3
- ASTM B241, EN755-8, GB/T4437.1-2000, JIS H4080
- ISO 9001, 14001, 8573-1
Warranty
- 10-Year Warranty on all AP Stainless fittings
The ANSI Aluminum Flange is a critical component for contractors seeking a durable, leak-proof, and standards-compliant solution for bolted connections in industrial piping systemsโdelivering performance, safety, and long-term reliability.
Additional information
| Weight | N/A |
|---|---|
| ANSI Flange | 100mm (4"), 150mm (6"), 200mm (8"), 250mm (10"), 63mm (2-1/2"), 80mm (3") |
| AIRpipe Certification | ASME, ASTM, CE, CRN, EN, ISO 14001, ISO 8573-1, ISO 9001, TS, TUV, UL |
| Color | Gray |
| Connection | Lugged Ring Clamping Style |
| Features | Bolts and Gasket Included |
| AIRpipe Outer Dimension | 100mm (4"), 150mm (6"), 200mm (8"), 250mm (10"), 63mm (2-1/2"), 80mm (3") |
| Material | Aluminum |
| Pressure | 188 PSI, 232 PSI, 300 PSI, 29.9 inHg (99% vacuum) |
| Temperature | -4ยฐF to +176ยฐF |
