Female NPT Tee
Female NPT Tee
The 304 Stainless Steel Female NPT Tee is designed to connect three male-threaded components in industrial piping systems, allowing for a branch connection at a 90-degree angle. Contractors use this fitting to split or combine flow in systems handling water, steam, air, or chemicals. With female NPT threads on all three ends, it offers a secure, leak-resistant connection using standard tools and thread sealant. Its corrosion-resistant stainless steel construction ensures long-term durability in demanding environments. Ideal for system layouts requiring directional changes or flow distribution, the Female NPT Tee simplifies installation and supports reliable performance under pressure.
Key Features
- Proven Technology: Simple and robust threaded connection ensures long-term system reliability.
- Flameless Installation: No welding or solderingโreduces installation and repair time by over 50%.
- Versatile Conveyance: Seal and material options allow for the conveyance of nearly any liquid or gas.
- Dynamic System Response: Elastomeric connections absorb vibration, expansion, and contraction.
- Corrosion Resistance: Chromium dioxide layer protects against rust and environmental degradation.
- Fluid Safety: No risk of contamination to conveyed fluids.
- UV Stability: No impact from UV exposure, ideal for outdoor installations.
Size Range
- Available Sizes: 1/2" to 1 1/4"
- Connection Type: Female NPT threads on all three ends
- Built-in Sealing: Designed for gases and liquids
- Extended Fitting Sleeve: Maintains pipe alignment and flow efficiency
Material & Seals
- Material: 304 Stainless Steel
- Seals:
- EPDM (standard for press connections)
- FKM (for high temperature and chemical resistance)
Applications
- Chilled/Cooled Water
- Hot Water
- Process Water
- Low Pressure Steam
- Compressed Air & Inert Gases
- Vacuum Systems
- Chemicals & Hydraulic Oils
- Acid & Caustic Solutions
- Wastewater
- Diesel Exhaust Fluid (DEF)
Certifications
- ASME B31.1, B31.3, B31.9
- ASTM A312
- ISO 9001, 14001, 45001
Warranty
- 10-Year Warranty on all AP Stainless fittings
Additional information
| Weight | N/A |
|---|---|
| Female NPT Tee | 1-1/4" Pipe to 1-1/4" Female NPT, 1-1/4" Pipe to 1" Female NPT, 1" Pipe to 1" Female NPT, 1" Pipe to 1/2" Female NPT, 1" Pipe to 3/4" Female NPT, 1/2" Pipe to 1/2" Female NPT, 3/4" Pipe to 1/2" Female NPT, 3/4" Pipe to 3/4" Female NPT |
| AP Stainless Certification | ASME, CE, EN, ISO 14001, ISO 45001, ISO 9001, TS, TUV, UL |
| Color | Blue, Silver Metallic |
| Connection | Press, Threaded |
| Features | High Flow |
| Material | Stainless Steel |
| Pressure | 188 PSI, 1mbar/0.03inhg (Full industrial vacuum), 200 PSI |
| Temperature | EPDM -4ยฐF to +248ยฐF |
